Information accessible  from anywhere throughout the web

Revealing factory information wherever and in real time is a strategical must-have that any manufacturing company is well aware of.  This is the reason why Progea has especially designed Movicon™ Web Client, the innovative software solution based on the most modern Thin Client Java technologies for sharing real-time data across internet or intranet network architectures.

Thanks to the Movicon™11 and Movicon™ Web Client technologies you can visualize and control any Movicon™ HMI or Scada supervision station using a simple browser on the client, saving you major costs in management, maintenance and licensing, while increasing your company productivity at the same time.

Truly Web-based Architecture .
Movicon™ Web Client uses the Thin Client model, thanks to which the whole application resides and is processed on the server.   This consents to information centralization, making system management and maintenance simple and low-costing.  The Client displays graphics processed on the server through any Internet browser, by interacting and adapting the graphical resolution to  local requirements.  Updates are dispatched to the Client only on event, upon each change.  The most advanced technologies (Java, XML, Web Services) and exception technology guarantee performances and a truly innovative architecture.






Unmatched Potentiality throughout the Web .
Client users, without installing and processing any thing on Client stations, are fully aided with the potentiality that only the Movicon™ Web Client is capable of offering.  The graphical representations of screens are shown in their ‘true colors' and graphics are automatically adapted to the client's graphic resolutions or to the size of the browser window.   On the Client side you can interact with and activate commands and manage events of VBA code inserted in symbols.   All information from Historical Logs, Trends can be obtained and data tables displayed with filter and order by support.   The Scheduler and IP Camera viewer objects are supported along with their interactivities.   The Movicon™ Web Client potentialities are incredibly outstanding, powerful, extremely simple and automatic, truly making the automation-over-the web concept a real ‘live wire'.

















  • Web Client features
    Movicon™ Web Client offers the possibility to access factory data using Internet/Intranet architectures.  The advantages you get from using the Movicon™ Web Client are:

    • Accessing and displaying projects over the web using any browser with any operating system, made possible by Java technology support, and in the J2ME version for supporting the JavaPhones technology.  Creating Web pages on the server is completely automatic with one click only.
    • Project screen navigation as predefined on server, possible restrictions may occur navigating on the Web side.
    • No need to install or configure extra on Client or Server.
    • Enhanced performances, transparent support to the project functionalities and commands using a normal browser.
    • Secure data management.
    • Notification on exception only
    • Communications based on Web Services.
    • Entirely Java-based technology.
    • Support to Applet J2SE and Midlet J2ME.
    • Multiplatform support on Client side (Linux, Windows™, Palm, Symbian, Javaphones).
    • Support to Windows Vista/XP or Windows CE on Server side
    • Access to Server by mobile phone acting as plant system client.
    • Complete access from Web side to historicals recorded by Server
    • Support to powerful functions such as schedulers or IP camera viewers.
    • midlet

      Web Client becomes mobile!
      Movicon™ Web Client is the only Scada/HMI in the world that allows Web Clients to log on with mobile phone devices, all made possible with the Web client Midlet, to consent access to the supervisor using normal mobile phones with Java J2ME 2.0 support.  Users can now receive event notifications over the phone, connect immediately to the plant system (GPRS/UMTS) to get information on tags, alarms, historicals and even display and interact with screens wherever they happen to be.







Movicon is a Progea registered trademark and all rights are reserved.

Movicon is certified as "Designed for Windows XP" by Microsoft and is tested and certified by OPC Foundation.
