SPEED7 314SE DPs -256kB
Part No: VIPA 314-2BG23
.
CPU 314SE/DPs – SPEED7 Technology

Programmed by STEP7 from Siemens or WinPLC7 from VIPA or TIA Portal from Siemens
DC 24V
256kByte memory, expandable up to 1MByte work memory,(50% program + 50% data)
MPI interface, 187.5 to 12Mb!
MMC slot,
real time clock,
2048/2048byte I/O address area
512 timers (IEC timers unlimited)
512 Counters (IEC Counters unlimited)
8192 flag byte
Firmware upgrade via MMC
Ethernet interface for PG/OP communication, up to 4 connections
Profibus-DP slave, 12MBaud
Profibus port switchable to PtP port RS485, supports ASCII, 3964R, STX/ETX, USS and Modbus
32 Modules per rack, or up to 4 split racks
The new SPEED7 CPU's from VIPA are the fastest PLC in the world, more than 10x faster than the Siemens S7-400 CPU's the VIPA SPEED7 can handle the biggest applications. The memory is not fixed in size, it is expandable by purchasing a MMC memory upgrade, so your plant cost life cycle is reduced.
